Schneider Electric JRA36250 Molded Case Circuit Breaker 600V 250A

(No reviews yet) Write a Review

Write a Review

Schneider Electric JRA36250 Molded Case Circuit Breaker 600V 250A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

JRA36250

UPC:

7.85901E+11

MPN:

Condition:

New

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Quality Labels:

CE

Ip Degree Of Protection:

front cover IP40

Width:

104 mm

Poles Description:

3P

Pvc Free:

Yes

Local Signalling:

switched off (OFF) 1 trip indicator green)

Product Certifications:

UL || CSA || NOM

Circularity Profile:

ENVEOLI2206031EN

Circuit Breaker Application:

HACR rated

Tightening Torque:

25-25 N.m 95-185 mm² (AWG 3/0...350 kcmil)

Ambient Air Temperature For Storage:

-50-85 °C

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Rohs Exemption Information:

Yes

Mercury Free:

Yes

Environmental Disclosure:

ENVPEP2206031EN

Awg Gauge:

AWG 3/0...350 kcmil aluminium/copper terminals

Protection Type:

overload protection || short-circuit protection

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Depth:

86 mm

Sustainable Offer Status:

Green Premium product

Wire Stripping Length:

25 mm

[Ics] Rated Service Breaking Capacity:

150 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 125 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 75 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 690 V AC 50/60 Hz IEC 60947-2

Phase Connection:

ABC

Product Or Component Type:

circuit breaker

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Line Rated Current:

250-250 A

Mounting Support:

bracket

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Magnetic Tripping Current:

2500-2500 A

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Mounting Mode:

I-Line bracket)

Suitability For Isolation:

yes IEC 60947-2

Terminal Identifier:

AL250JD

Network Frequency:

50/60 Hz

Electrical Connection:

I-Line connection, line || lugs, load

Continuous Current Rating:

0.8

[Ue] Rated Operational Voltage:

600 V AC 50/60 Hz IEC 60947-3

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 5000 m with derating

Eu Rohs Directive:

Compliant with Exemptions

Utilisation Category:

category A

Mounting Height:

4.5 in

Net Weight:

2.4 kg

Breaking Capacity Code:

R

Pollution Degree:

3

Communication Interface:

Modbus

Breaking Capacity:

200 kA 240 V AC 50/60 Hz UL 489 || 200 kA 480 V AC 50/60 Hz UL 489 || 100 kA 600 V AC 50/60 Hz UL 489

Trip Unit Technology:

thermal-magnetic

Magnetic Hold Current:

1250 A

Height:

191 mm

Control Type:

toggle

Ambient Air Temperature For Operation:

-2-70 °C

Long Time Pick-Up Adjustment Range:

0.25...1 x In

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
