Schneider Electric LA26200AC Molded Case Circuit Breaker 600V 200A
Schneider Electric
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Circuit breaker, LA, I-Line, 200A, 2 pole, 600VAC, phase AC
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Magnetic Tripping Current:
- 2000-2000 A
- Terminal Identifier:
- AL400LA
- Depth:
- 5.84 in
- Environmental Disclosure:
- ENVPEP1410004EN
- Rohs Exemption Information:
- Yes
- Line Rated Current:
- 200 A
- Electrical Connection:
- lugs, load || I-Line connection, line
- Halogen Content Performance:
- Halogen free plastic parts product
- Sustainable Offer Status:
- Green Premium product
- Trip Unit Technology:
- thermal-magnetic
- Height:
- 11 in
- Tightening Torque:
- 13-13 N.m 42-304 mm² (AWG 1...600 kcmil) || 13-13 N.m 42-127 mm² (AWG 1...250 kcmil)
- Mounting Mode:
- I-Line
- Width:
- 6 in
- Warranty:
- 18 months
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Poles Description:
- 2P
- Product Certifications:
- CSA || UL Listed
- Breaking Capacity Code:
- A
- Magnetic Hold Current:
- 1000 A
- Eu Rohs Directive:
- Compliant with Exemptions
- Phase Connection:
- AC
- Pvc Free:
- Yes
- Product Or Component Type:
- circuit breaker
- Circularity Profile:
- N/A
- Wiring Configuration:
- 2-wire
- Circuit Breaker Application:
- HACR rated
- Mercury Free:
- Yes
- Catalog:
- View
- Datasheet:
- View
