Schneider Electric LA26300AB Molded Case Circuit Breaker 600V 300A
SKU:
LA26300AB
UPC:
785901529491
MPN:
Condition:
New
Mercury Free:
Yes
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Circuit Breaker Application:
HACR rated
Phase Connection:
AB
Rohs Exemption Information:
Yes
Width:
6 in
Poles Description:
2P
Wiring Configuration:
2-wire
Product Certifications:
CSA || UL Listed
Trip Unit Technology:
thermal-magnetic
Breaking Capacity Code:
A
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Sustainable Offer Status:
Green Premium product
Height:
11 in
Eu Rohs Directive:
Compliant with Exemptions
Line Rated Current:
300 A
Warranty:
18 months
Magnetic Hold Current:
1500 A
Electrical Connection:
lugs, load || I-Line connection, line
Halogen Content Performance:
Halogen free plastic parts product
Product Or Component Type:
circuit breaker
Magnetic Tripping Current:
3000-3000 A
Depth:
5.84 in
Circularity Profile:
N/A
Mounting Mode:
I-Line
Pvc Free:
Yes
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
The PowerPact H-, J-, and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. L-frame circuit breakers are available with...
Square D LA molded case circuit breakers provide thermal magnetic protection. Their primary function is automatic opening of a circuit under overload or short circuit conditions or manual opening. LA...
Square D FA/LA Molded Case Circuit Breakers is designed to protect electrical systems from damage caused by overloads. For distribution systems supplied by transformers and distribution systems...
