Schneider Electric LAL26200 Molded Case Circuit Breaker 600V 200A

Schneider Electric LAL26200 Molded Case Circuit Breaker 600V 200A

Schneider Electric
SKU:
LAL26200
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$3,807.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
Square D LA molded case circuit breakers provide thermal magnetic protection. Their primary function is automatic opening of a circuit under overload or short circuit conditions or manual opening. LA circuit breakers contain thermal (overload) and magnetic (short circuit) sensing elements in each pole. Push-to-Trip allows the circuit breaker to be manually tripped without exposure to live parts. This Square D LA molded case circuit breaker is a 2 pole unit mount breaker, 200A and 600VAC. The thermal magnetic circuit breaker has an interrupting rating of 22kA for 600VAC and 10kA for 250VDC. LA breakers are UL 489, CSA, IEC certified.
Additional Information
Rohs Exemption Information:
Yes
Trip Unit Technology:
thermal-magnetic
Line Rated Current:
200 A
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Sustainable Offer Status:
Green Premium product
Magnetic Tripping Current:
2000-2000 A
Eu Rohs Directive:
Compliant with Exemptions
Terminal Identifier:
AL400LA
Product Certifications:
UL Listed || CSA || IEC
Circuit Breaker Application:
HACR rated
Poles Description:
2P
Environmental Disclosure:
ENVPEP1410004EN
Height:
11 in
Circularity Profile:
N/A
Depth:
5.84 in
Pvc Free:
Yes
Product Or Component Type:
circuit breaker
Warranty:
18 months
Mercury Free:
Yes
Electrical Connection:
lugs, load || lugs, line
Mounting Mode:
unit mount
Tightening Torque:
13-13 N.m 42-304 mm² (AWG 1...600 kcmil) || 13-13 N.m 42-127 mm² (AWG 1...250 kcmil)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Magnetic Hold Current:
1000 A
Halogen Content Performance:
Halogen free plastic parts product
Width:
6 in
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
