Schneider Electric LH36125 Molded Case Circuit Breaker 600V 125A
Schneider Electric
$12,217.50
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Circuit breaker, LH, I-Line, 125A, 3 pole, 25kA, 600VAC, 50kA, 250VDC, phase ABC
- Breaking Capacity Code:
- H
- Warranty:
- 18 months
- Circularity Profile:
- N/A
- Circuit Breaker Application:
- HACR rated
- Trip Unit Technology:
- thermal-magnetic
- Width:
- 6 in
- Magnetic Tripping Current:
- 1250-1250 A
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Terminal Identifier:
- AL400LA
- Eu Rohs Directive:
- Compliant with Exemptions
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Halogen Content Performance:
- Halogen free plastic parts product
- Mercury Free:
- Yes
- Rohs Exemption Information:
- Yes
- Magnetic Hold Current:
- 625 A
- Environmental Disclosure:
- ENVPEP1410004EN
- Pvc Free:
- Yes
- Height:
- 12.5 in
- Line Rated Current:
- 125 A
- Depth:
- 4 in
- Poles Description:
- 3P
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Sustainable Offer Status:
- Green Premium product
- Electrical Connection:
- lugs, load || I-Line connection, line
- Product Or Component Type:
- circuit breaker
- Product Certifications:
- CSA || UL Listed
- Mounting Mode:
- I-Line
- Tightening Torque:
- 13-13 N.m 42-304 mm² (AWG 1...600 kcmil) || 13-13 N.m 42-127 mm² (AWG 1...250 kcmil)
- Datasheet:
- View
