Schneider Electric LHL36200 Molded Case Circuit Breaker 600V 200A
Schneider Electric
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Square D LH molded case circuit breakers provide thermal magnetic protection. Their primary function is automatic opening of a circuit under overload or short circuit conditions or manual opening. LH circuit breakers contain thermal (overload) and magnetic (short circuit) sensing elements in each pole. Push-to-Trip allows the circuit breaker to be manually tripped without exposure to live parts. This Square D LH molded case circuit breaker is a 3 pole unit mount breaker, 200A and 600VAC. The thermal magnetic circuit breaker has an interrupting rating of 25kA for 600VAC and 50kA for 250VDC. LH breakers are UL 489, CSA, IEC certified.
- Environmental Disclosure:
- ENVPEP1410004EN
- Pvc Free:
- Yes
- Line Rated Current:
- 200 A
- Product Or Component Type:
- circuit breaker
- Magnetic Tripping Current:
- 2000-2000 A
- Tightening Torque:
- 13-13 N.m 42-304 mm² (AWG 1...600 kcmil) || 13-13 N.m 42-127 mm² (AWG 1...250 kcmil)
- Trip Unit Technology:
- thermal-magnetic
- Rohs Exemption Information:
- Yes
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Product Certifications:
- UL Listed || IEC || CSA
- Mounting Mode:
- unit mount
- Halogen Content Performance:
- Halogen free plastic parts product
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Sustainable Offer Status:
- Green Premium product
- Electrical Connection:
- lugs, load || lugs, line
- Magnetic Hold Current:
- 1000 A
- Depth:
- 5.84 in
- Terminal Identifier:
- AL400LA
- Mercury Free:
- Yes
- Circuit Breaker Application:
- HACR rated
- Poles Description:
- 3P
- Circularity Profile:
- N/A
- Breaking Capacity Code:
- H
- Warranty:
- 18 months
- Eu Rohs Directive:
- Compliant with Exemptions
- Width:
- 6 in
- Height:
- 11 in
- Catalog:
- View
- Datasheet:
- View
