Schneider Electric LHP36400MT Molded Case Circuit Breaker 600V 400A

Schneider Electric LHP36400MT Molded Case Circuit Breaker 600V 400A

Schneider Electric
SKU:
LHP36400MT
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$11,397.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
Circuit breaker, LH, unit mount, 400A, 3 pole, 25kA, 600VAC, 50kA, 250VDC, plug on shroud
Additional Information
Breaking Capacity Code:
H
Circuit Breaker Application:
HACR rated
Trip Unit Technology:
thermal-magnetic
Height:
12.5 in
Terminal Identifier:
AL400LA
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Depth:
4 in
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Certifications:
UL Listed || CSA
Magnetic Hold Current:
2000 A
Environmental Disclosure:
ENVPEP1410004EN
Rohs Exemption Information:
Yes
Eu Rohs Directive:
Compliant
Poles Description:
3P
Electrical Connection:
lugs, line || terminal, load
Sustainable Offer Status:
Green Premium product
Product Or Component Type:
circuit breaker
Halogen Content Performance:
Halogen free plastic parts product
Magnetic Tripping Current:
4000-4000 A
Width:
6 in
Line Rated Current:
400 A
Warranty:
18 months
Mounting Mode:
unit mount
Pvc Free:
Yes
Mercury Free:
Yes
Tightening Torque:
13-13 N.m 42-304 mm² (AWG 1...600 kcmil) || 13-13 N.m 42-127 mm² (AWG 1...250 kcmil)
Datasheet:
View
