Schneider Electric LUFW10 Alarm Module 105%Flc

Schneider Electric LUFW10 Alarm Module 105%Flc

Schneider Electric
SKU:
LUFW10
|
UPC:
3389110365511
Availability:
Contact us to confirm availability and lead times.
$156.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
TeSys U additional function module to be inserted in advanced power bases LUB120, LUB320, LUB380 for thermal overload alarm. It provides 1NO instantaneous contact rated 2A 230V AC / 24V DC, a LED status on front panel. The alarm is activated when the thermal overload state exceeds 88% of thermal tripping state, with an hysteresis of 5% between activation and deactivation. It is powered by the control unit. Certified when used in conjunction with a LUB power base (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
Additional Information
Net Weight:
0.055 kg
Mounting Mode:
plug-in
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Mounting Location:
front side
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Environmental Disclosure:
ENVPEP111201EN
Associated Cable Type:
AWG24...AWG16
Product Compatibility:
LUCC || LUCB || LUCD
Function Available:
thermal overload alarm
Auxiliary Contact Composition:
1 NO
Connection Pitch:
5.08 mm
Discrete Output Function:
1 NO AC-15) 230 V 400 VA 100000 cycles || 1 NO DC-13) 24 V 50 W 100000 cycles
Rohs Exemption Information:
Yes
Sustainable Offer Status:
Green Premium product
Tightening Torque:
0.5-0.6 N.m 3.5 mm flat
Short-Circuit Protection:
2 A fuse gG IEC 60947-5-1
Circularity Profile:
ENVEOLI111214EN_V1
Eu Rohs Directive:
Compliant with Exemptions
Range:
TeSys
Warranty:
18 months
Communication Of Faults:
LED front panel
Product Or Component Type:
function module
Mercury Free:
Yes
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Device Short Name:
LUF
[Ith] Conventional Free Air Thermal Current:
2 A 70 °C
Connections - Terminals:
screw clamp terminals 2 0.2-1 mm² rigid without cable end || screw clamp terminals 2 0.25-1 mm² flexible with cable end || screw clamp terminals 2 0.5-1 mm² flexible with cable end || screw clamp terminals 1 0.2-1.5 mm² flexible without cable end
