Schneider Electric LV426843 Coil Mx Ac 110-130 V 50/60 Hz

Schneider Electric LV426843 Coil Mx Ac 110-130 V 50/60 Hz

Schneider Electric
SKU:
LV426843
|
UPC:
3606485413068
Availability:
Factory stock
$419.69
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This standard MX shunt trip is used on Compact NSXm and PowerPact B devices. This auxiliary is used for emergency off or failsafe remote opening applications. It is a one click spring type auxiliary for quick and easy installation, visible from the front face of the device. This MX auxiliary has a 110/130 VAC 50/60Hz or 125VDC rated voltage. It trips the circuit breaker when the control voltage rises above 70% of its rated value. It complies with IEC 60947-2 standard. Compact NSXm and PowerPact B embed either 1 MN or 1 MX coil.
Additional Information
Range Of Product:
ComPacT NSXm new generation
Circularity Profile:
ENVEOLI2311043EN
Auxiliary Connection Terminal:
spring
Mercury Free:
Yes
Rohs Exemption Information:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Control Signal Type:
impulse || maintained
Impulse Duration:
>= 20 ms
Control Type:
standard
Device Short Name:
MX
Device Application:
control
[Uc] Control Circuit Voltage:
110...130 V AC 50/60 Hz || 125 V DC
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Voltage Release Type:
opening coil || shunt trip release
Product Or Component Type:
voltage release
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Threshold Tripping Voltage:
0.7 Un opening
Range Compatibility:
ComPact ComPacT NSXm new generation || ComPact ComPact NSXm || PowerPact PowerPact B
Response Time:
< 50 ms
Environmental Disclosure:
ENVPEP2311043EN
Sustainable Offer Status:
Green Premium product
Range:
ComPact
