Schneider Electric LV426963 Circuit Breaker Terminial Nut Kit 3 Pc
Schneider Electric
Schneider Electric LV426962 Circuit Breaker Terminial Nut Kit (2 Pc)
Schneider Electric
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT B-Frame circuit breakers offer a whole range of field installable accessories, allowing modifying the circuit breaker at any time in the design and build cycle. PowerPacT B-Frame circuit breakers may be equipped with terminal nuts and M6 power screws for direct connection to compression lugs, power distribution connectors, busbars and terminal spreaders. This PowerPacT B, terminal nut insert can replace the EverLink lug. The terminal nuts have a rated current of 15A to 125A. The kit contains two terminal nut inserts. They are also available factory installed.
- Pvc Free:
- Yes
- Sustainable Offer Status:
- Green Premium product
- Line Rated Current:
- 15-125 A
- Product Or Component Type:
- terminal kit
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Halogen Content Performance:
- Halogen free product
- Quantity Per Set:
- set of 2
- Thread Type:
- M6
- Accessory / Separate Part Category:
- connection accessory
- Rohs Exemption Information:
- Yes
- Environmental Disclosure:
- ENVPEP1610005EN
- Poles Description:
- 2P
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- California Proposition 65:
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Eu Rohs Directive:
- Compliant with Exemptions
- Circularity Profile:
- N/A
- Mounting Mode:
- fixed
- Mercury Free:
- Yes
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
