Schneider Electric M9F14332 Multi9 C60H 3P C 32A 15Ka 415V Mcb

(No reviews yet) Write a Review
SKU:
M9F14332
UPC:
3.60648E+12
Condition:
New
Color:
Gray
Mercury Free:
Yes
Tropicalisation:
2 IEC 60068-1
Ambient Air Temperature For Storage:
-40-80 °C
Magnetic Tripping Limit:
8.5 x In +/- 20 % AC || 12 x In +/- 20 % DC
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Net Weight:
0.36 kg
Eu Rohs Directive:
Compliant with Exemptions
Curve Code:
C
Ambient Air Temperature For Operation:
-30-70 °C
[Ue] Rated Operational Voltage:
240 V AC 50/60 Hz between phases || 415 V AC 50/60 Hz between phases || 440 V AC 50/60 Hz between phases || <= 125 V DC
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Name:
Multi9 C60
Tightening Torque:
3.5-3.5 N.m top or bottom
Rohs Exemption Information:
Yes
Poles Description:
3P
Device Application:
distribution
Product Or Component Type:
miniature circuit-breaker
Sustainable Offer Status:
Green Premium product
Relative Humidity:
95-95 % 55-55 °C
9 Mm Pitches:
6
Suitability For Isolation:
yes EN/IEC 60947-2
Connections - Terminals:
tunnel type terminal top or bottom) 1.5-35 mm² - rigid || tunnel type terminal top or bottom) 1.5-35 mm² - flexible || tunnel type terminal top or bottom) 1.5-35 mm² - flexible with ferrule
[Ui] Rated Insulation Voltage:
500 V AC 50/60 Hz EN/IEC 60947-2
Earth-Leakage Protection:
separate block
Breaking Capacity:
40 kA Icu <= 125 V DC EN/IEC 60947-2 || 30 kA Icu 240 V AC 50/60 Hz between phases EN/IEC 60947-2 || 15 kA Icu 415 V AC 50/60 Hz between phases EN/IEC 60947-2 || 10 kA Icu 440 V AC 50/60 Hz between phases EN/IEC 60947-2
[Uimp] Rated Impulse Withstand Voltage:
6 kVEN/IEC 60947-2
Mounting Support:
DIN rail
Device Short Name:
C60H
Mounting Mode:
clip-on
Heat Dissipation:
10.5-10.5 W 415 V - 32 A
[Ics] Rated Service Breaking Capacity:
15 kA 50 % EN/IEC 60947-2 - 240 V AC 50/60 Hz || 7.5 kA 50 % EN/IEC 60947-2 - 415 V AC 50/60 Hz || 5 kA 50 % EN/IEC 60947-2 - 440 V AC 50/60 Hz || 40 kA 100 % EN/IEC 60947-2 - <= 125 V DC
Contact Position Indicator:
yes
Network Frequency:
50/60 Hz
Control Type:
toggle
Product Certifications:
EAC || CCC
Circularity Profile:
N/A
Local Signalling:
ON/OFF indication
Network Type:
DC || AC
Ip Degree Of Protection:
IP20 conforming to IEC 60529 || IP40 (modular enclosure) conforming to IEC 60529
Halogen Content Performance:
Halogen free plastic parts & cables product
Wire Stripping Length:
14 mm for top or bottom connection
Range:
Multi9
Provision For Padlocking:
padlockable
Number Of Protected Poles:
3
Trip Unit Technology:
thermal-magnetic
Mechanical Durability:
20000 cycles
Height:
81 mm
Line Rated Current:
32 A 50 °C EN/IEC 60947-2
Utilisation Category:
category A EN/IEC 60947-2
Depth:
72 mm
Standards:
EN/IEC 60947-2
Overvoltage Category:
IV
Width:
54 mm
Environmental Disclosure:
ENVPEP1304004EN
Electrical Durability:
10000 cycles
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Pollution Degree:
3 EN/IEC 60947-2
Brochure:
View
Datasheet:
View
$389.00

Description

This Multi9 C60H is a low voltage miniature circuit breaker (MCB). It is a 3P circuit breaker with 3 protected poles, 32A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 15kA at 415VAC conforming to EN/IEC 60947-2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. It has been designed to offer enhanced protection by preventing, protecting people and equipment from electrical threats. This product protects from short circuit, earth leakage and overload. Its fast closing mechanism, overvolatge resistance and high performance limitation improve its service life. This product is dedicated for original equipment manufacturers (OEM) and control panel builders. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. The product can be clipped on a DIN rail. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is light grey (RAL7035). The dimensions are (W) 54mm x (H) 81mm x (D) 72mm. The weight is 0.36kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -30°C to 70°C. The storage temperature is -40°C to 80°C.
