Schneider Electric M9F15310 Multi9 C60H 3P D 10A 15Ka 415V Mcb
Schneider Electric
$583.50
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Multi9 C60H is a low voltage miniature circuit breaker (MCB). It is a 3P circuit breaker with 3 protected poles, 10A rated current and D tripping curve. The rated short circuit breaking capacity goes up to 15kA at 415VAC conforming to EN/IEC 60947-2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. It has been designed to offer enhanced protection by preventing, protecting people and equipment from electrical threats. This product protects from short circuit, earth leakage and overload. Its fast closing mechanism, overvolatge resistance and high performance limitation improve its service life. This product is dedicated for original equipment manufacturers (OEM) and control panel builders. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. The product can be clipped on a DIN rail. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is light grey (RAL7035). The dimensions are (W) 54mm x (H) 81mm x (D) 72mm. The weight is 0.36kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -30°C to 70°C. The storage temperature is -40°C to 80°C.
- [Ui] Rated Insulation Voltage:
- 500 V AC 50/60 Hz EN/IEC 60947-2
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Suitability For Isolation:
- yes EN/IEC 60947-2
- Provision For Padlocking:
- padlockable
- Ip Degree Of Protection:
- IP20 conforming to IEC 60529 || IP40 (modular enclosure) conforming to IEC 60529
- Ambient Air Temperature For Storage:
- -40-80 °C
- Depth:
- 72 mm
- Device Application:
- distribution
- Tightening Torque:
- 2-2 N.m top or bottom
- Tropicalisation:
- 2 IEC 60068-1
- Sustainable Offer Status:
- Green Premium product
- Utilisation Category:
- category A EN/IEC 60947-2
- Pollution Degree:
- 3 EN/IEC 60947-2
- Heat Dissipation:
- 5.4-5.4 W 415 V - 10 A
- Environmental Disclosure:
- ENVPEP1304004EN
- Electrical Durability:
- 10000 cycles
- Width:
- 54 mm
- Curve Code:
- D
- Poles Description:
- 3P
- Breaking Capacity:
- 40 kA Icu <= 125 V DC EN/IEC 60947-2 || 30 kA Icu 240 V AC 50/60 Hz between phases EN/IEC 60947-2 || 15 kA Icu 415 V AC 50/60 Hz between phases EN/IEC 60947-2 || 10 kA Icu 440 V AC 50/60 Hz between phases EN/IEC 60947-2
- Mechanical Durability:
- 20000 cycles
- Wire Stripping Length:
- 14 mm for top or bottom connection
- Contact Position Indicator:
- yes
- Mercury Free:
- Yes
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Magnetic Tripping Limit:
- 12 x In +/- 20 % AC || 17 x In +/- 20 % DC
- [Ue] Rated Operational Voltage:
- 240 V AC 50/60 Hz between phases || 415 V AC 50/60 Hz between phases || 440 V AC 50/60 Hz between phases || <= 125 V DC
- Earth-Leakage Protection:
- separate block
- Ambient Air Temperature For Operation:
- -30-70 °C
- Rohs Exemption Information:
- Yes
- Eu Rohs Directive:
- Compliant with Exemptions
- Connections - Terminals:
- tunnel type terminal top or bottom) 1-25 mm² - rigid || tunnel type terminal top or bottom) 1-25 mm² - flexible || tunnel type terminal top or bottom) 1-25 mm² - flexible with ferrule
- Line Rated Current:
- 10 A 50 °C EN/IEC 60947-2
- Network Frequency:
- 50/60 Hz
- Trip Unit Technology:
- thermal-magnetic
- Height:
- 81 mm
- Product Name:
- Multi9 C60
- [Ics] Rated Service Breaking Capacity:
- 15 kA 50 % EN/IEC 60947-2 - 240 V AC 50/60 Hz || 7.5 kA 50 % EN/IEC 60947-2 - 415 V AC 50/60 Hz || 5 kA 50 % EN/IEC 60947-2 - 440 V AC 50/60 Hz || 40 kA 100 % EN/IEC 60947-2 - <= 125 V DC
- Mounting Support:
- DIN rail
- Halogen Content Performance:
- Halogen free plastic parts & cables product
- Standards:
- EN/IEC 60947-2
- Net Weight:
- 0.36 kg
- Product Certifications:
- EAC || CCC
- Device Short Name:
- C60H
- Relative Humidity:
- 95-95 % 55-55 °C
- [Uimp] Rated Impulse Withstand Voltage:
- 6 kVEN/IEC 60947-2
- Range:
- Multi9
- Network Type:
- AC || DC
- 9 Mm Pitches:
- 6
- Local Signalling:
- ON/OFF indication
- Control Type:
- toggle
- Circularity Profile:
- N/A
- Color:
- Gray
- Overvoltage Category:
- IV
- Mounting Mode:
- clip-on
- Number Of Protected Poles:
- 3
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Product Or Component Type:
- miniature circuit-breaker
- Brochure:
- View
- Datasheet:
- View
