Schneider Electric M9F17302 Multi9 C60L 3P C 2A 25Ka 240 V Mcb

Schneider Electric M9F17302 Multi9 C60L 3P C 2A 25Ka 240 V Mcb

Schneider Electric
SKU:
M9F17302
|
UPC:
3606480578090
$718.50
(No reviews yet) Write a Review
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This Multi9 C60L is a low voltage miniature circuit breaker (MCB). It is a 3P circuit breaker with 3 protected poles, 2A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 25kA at 415VAC conforming to EN/IEC 60947-2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. It has been designed to offer enhanced protection by preventing, protecting people and equipment from electrical threats. This product protects from short circuit, earth leakage and overload. Its fast closing mechanism, overvolatge resistance and high performance limitation improve its service life. This product is dedicated for original equipment manufacturers (OEM) and control panel builders. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. The product can be clipped on a DIN rail. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is light grey (RAL7035). The dimensions are (W) 54mm x (H) 81mm x (D) 72mm. The weight is 0.36kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -30°C to 70°C. The storage temperature is -40°C to 80°C.
Additional Information
Rohs Exemption Information:
Yes
Heat Dissipation:
7.8-7.8 W 415 V - 2 A
Pollution Degree:
3 EN/IEC 60947-2
Net Weight:
0.36 kg
Mercury Free:
Yes
Wire Stripping Length:
14 mm for top or bottom connection
Product Name:
Multi9 C60
Sustainable Offer Status:
Green Premium product
Halogen Content Performance:
Halogen free plastic parts & cables product
Limitation Class:
3
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Local Signalling:
ON/OFF indication
Earth-Leakage Protection:
separate block
Width:
54 mm
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Color:
Gray
Poles Description:
3P
Circularity Profile:
N/A
Suitability For Isolation:
yes EN/IEC 60947-2
Magnetic Tripping Limit:
8.5 x In +/- 20 % AC || 12 x In +/- 20 % DC
[Ue] Rated Operational Voltage:
240 V AC 50/60 Hz between phases || 415 V AC 50/60 Hz between phases || 440 V AC 50/60 Hz between phases || <= 125 V DC
Tropicalisation:
2 IEC 60068-1
Ambient Air Temperature For Storage:
-40-80 °C
Depth:
72 mm
[Ui] Rated Insulation Voltage:
500 V AC 50/60 Hz EN/IEC 60947-2
Eu Rohs Directive:
Compliant with Exemptions
Network Type:
AC || DC
Device Short Name:
C60L
Overvoltage Category:
IV
Line Rated Current:
2 A 50 °C EN/IEC 60947-2
Breaking Capacity:
50 kA Icu <= 125 V DC EN/IEC 60947-2 || 50 kA Icu 240 V AC 50/60 Hz between phases EN/IEC 60947-2 || 25 kA Icu 415 V AC 50/60 Hz between phases EN/IEC 60947-2 || 20 kA Icu 440 V AC 50/60 Hz between phases EN/IEC 60947-2
Number Of Protected Poles:
3
Tightening Torque:
2-2 N.m top or bottom
Control Type:
toggle
Relative Humidity:
95-95 % 55-55 °C
Trip Unit Technology:
thermal-magnetic
Ip Degree Of Protection:
IP20 conforming to IEC 60529 || IP40 (modular enclosure) conforming to IEC 60529
Utilisation Category:
category A EN/IEC 60947-2
Device Application:
distribution
Mounting Mode:
clip-on
Ambient Air Temperature For Operation:
-30-70 °C
Mounting Support:
DIN rail
Environmental Disclosure:
ENVPEP1304004EN
9 Mm Pitches:
6
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Certifications:
EAC || CCC
Provision For Padlocking:
padlockable
Connections - Terminals:
tunnel type terminal top or bottom) 1-25 mm² - rigid || tunnel type terminal top or bottom) 1-25 mm² - flexible || tunnel type terminal top or bottom) 1-25 mm² - flexible with ferrule
Contact Position Indicator:
yes
[Ics] Rated Service Breaking Capacity:
25 kA 50 % EN/IEC 60947-2 - 240 V AC 50/60 Hz || 12.5 kA 50 % EN/IEC 60947-2 - 415 V AC 50/60 Hz || 10 kA 50 % EN/IEC 60947-2 - 440 V AC 50/60 Hz || 50 kA 100 % EN/IEC 60947-2 - <= 125 V DC
Network Frequency:
50/60 Hz
Range:
Multi9
Electrical Durability:
10000 cycles
Curve Code:
C
Product Or Component Type:
miniature circuit-breaker
[Uimp] Rated Impulse Withstand Voltage:
6 kVEN/IEC 60947-2
Standards:
EN/IEC 60947-2
Mechanical Durability:
20000 cycles
Height:
81 mm
