Schneider Electric M9R81425 Multi9 Gfp 4P 25A 26Ma A-Si 480Y/277V
This Multi GFP product is a residual current circuit breaker (RCCB). It is a 4P circuit breaker with 25A In rated current, 26mA earth leakage sensitivity and A-SI type protection class. It protects persons against electric shock by direct contact. It also protects installations against fire risks. The tripping upon fault is indicated by a red mechanical status indicator on the front panel. The A-SI type offers enhanced immunity to electrical disturbances. This product is dedicated to original equipment manufacturers (OEM) and control panel builders in indisutrial and tertiary buildings. It is compliant with IEC/EN 61008-1 standard. The (Im/IΔm) rated breaking and making short circuit capacity is 1500A. The (Inc/IΔc) conditional rated short circuit current is 10kA. It has a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 440VAC. The Uimp rated impulse withstand voltage is 6kV. The frequency is 50Hz or 60Hz. It is DIN rail mountable. The width in 9mm pitches is 8. The product colour is light grey (RAL7035). The dimensions are (W) 72mm x (H) 81mm x (D) 60mm. The weight is 0.45kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is from -25°C to 60°C. The storage temperature is from -40°C to 70°C.
- Locking Options Description:
- padlocking in OFF position
- Utilisation Category:
- AC-23A EN/IEC 61008-1
- Earth-Leakage Protection Class:
- type A-SI (Super Immunised)
- Residual Current Tripping Technology:
- voltage independent
- Rohs Exemption Information:
- Yes
- Relative Humidity:
- 95-95 % 55-55 °C
- Earth-Leakage Protection Time Delay:
- instantaneous
- Mounting Support:
- DIN rail
- Network Type:
- AC
- Electromagnetic Compatibility:
- 8/20 µs impulse withstand, 3000 A EN/IEC 61008-1
- 9 Mm Pitches:
- 8
- Contact Position Indicator:
- yes
- Sustainable Offer Status:
- Green Premium product
- Depth:
- 60 mm
- Mercury Free:
- Yes
- [Uimp] Rated Impulse Withstand Voltage:
- 6 kVEN/IEC 61008-1
- Mechanical Durability:
- 20000 cycles
- Pollution Degree:
- 3
- Neutral Position:
- left
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Environmental Disclosure:
- ENVPEP2301023EN
- Circularity Profile:
- N/A
- Eu Rohs Directive:
- Compliant with Exemptions
- Device Short Name:
- GFP
- Product Or Component Type:
- residual current circuit breaker (RCCB)
- Earth-Leakage Sensitivity:
- 26 mA UL 1053 || 30 mA EN/IEC 61008-1
- Poles Description:
- 4P
- Mounting Mode:
- clip-on
- [Ui] Rated Insulation Voltage:
- 440 V AC 50/60 Hz
- Height:
- 81 mm
- Ip Degree Of Protection:
- IP20 conforming to IEC 60529 || IP40 (modular enclosure) conforming to IEC 60529
- Color:
- Gray
- Product Name:
- Multi9 GFP
- Product Certifications:
- IEC || UL
- Standards:
- EN/IEC 61008-1 || UL 1053
- Ambient Air Temperature For Storage:
- -40-70 °C
- Width:
- 72 mm
- Rated Breaking And Making Capacity:
- Idm 1500 A EN/IEC 61008-1
- Line Rated Current:
- 25 A 40 °C EN/IEC 61008-1
- Network Frequency:
- 50/60 Hz
- Device Application:
- distribution
- Tightening Torque:
- 3.5-3.5 N.m top or bottom
- Ambient Air Temperature For Operation:
- -25-60 °C
- Rated Conditional Short-Circuit Current:
- Inc 10 kA 100 A gG
- Wire Stripping Length:
- 14 mm for top or bottom connection
- Control Type:
- toggle
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- [Ue] Rated Operational Voltage:
- 480Y/277 V AC 60 Hz || 415 V AC 50 Hz
- Net Weight:
- 0.45 kg
- Connections - Terminals:
- tunnel type terminals top or bottom) 1-25 mm² AWG 18...AWG 3) - flexible || tunnel type terminals top or bottom) 1-35 mm² AWG 18...AWG 2) - rigid || tunnel type terminals top or bottom) 1-25 mm² AWG 18...AWG 3) - flexible with ferrule
- Range:
- Multi9
- Tropicalisation:
- 2 IEC 60068-1
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Local Signalling:
- ON, OFF, fault trip
