Schneider Electric M9V14363 Multi9 Vigi C60 3P 63A 300Ma Ac
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Vigi C60 is a modular add-on residual current devices. It is a 3P and rated current is 63A. The earth leakage protection class is AC type with a sensitivity of 300mA and a voltage independent technology. This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards. This product is compliant with EN/IEC 61009-1 and EN/IEC 61009-2-1 standard. The Ue rated operational voltage is 400VAC or 415VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 4kV. The pollution degree is 3. It can be mounted on DIN rail. The width in 9mm pitches is 7. The product color is light grey (RAL7035). The dimensions are (W) 63mm x (H) 87mm x (D) 74mm. The weight is 210g. The degree of protection is IP20 and IP40 in an enclosure. The operating temperature is -5°C to 60°C. The storage temperature is -40°C to 60°C.
- Depth:
- 74 mm
- Electromagnetic Compatibility:
- 8/20 µs impulse withstand, 250 A EN/IEC 61009-1
- Network Type:
- AC
- Sustainable Offer Status:
- Green Premium product
- Ambient Air Temperature For Operation:
- -5-60 °C
- [Uimp] Rated Impulse Withstand Voltage:
- 4 kVEN/IEC 61009-1
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Pollution Degree:
- 3 IEC 61009
- Earth-Leakage Sensitivity:
- 300 mA EN/IEC 61009-1
- Tropicalisation:
- 2 IEC 60068-1
- Line Rated Current:
- 63 A EN/IEC 61009-1
- Warranty:
- 18 months
- Relative Humidity:
- 95-95 % 55-55 °C
- Height:
- 87 mm
- Ip Degree Of Protection:
- IP20 conforming to IEC 60529 || IP40 (modular enclosure) conforming to IEC 60529
- Circularity Profile:
- N/A
- Electrical Connection To Mcb:
- by screws
- Standards:
- EN/IEC 61009-1 || EN/IEC 61009-2-1
- Mounting Support:
- DIN rail
- Earth-Leakage Protection Time Delay:
- instantaneous
- Width:
- 63 mm
- Residual Current Tripping Technology:
- voltage independent
- Range:
- Multi9
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Net Weight:
- 210 g
- Network Frequency:
- 50 Hz
- Wire Stripping Length:
- 14 mm for bottom connection
- Product Or Component Type:
- add-on residual current devices
- Device Short Name:
- Vigi C60
- Earth-Leakage Protection Class:
- type AC
- Ambient Air Temperature For Storage:
- -40-60 °C
- Range Compatibility:
- Multi9 Multi9 C60 C60N || Multi9 Multi9 C60 C60L || Multi9 Multi9 C60 C60H || Multi9 Multi9 C60 C60CTRL
- Mercury Free:
- Yes
- [Ui] Rated Insulation Voltage:
- 500 V AC 50 Hz EN/IEC 61009-1
- Mounting Mode:
- clip-on
- Connections - Terminals:
- tunnel type terminal bottom) 1-35 mm² - rigid || tunnel type terminal bottom) 1-25 mm² - flexible || tunnel type terminal bottom) 1-25 mm² - flexible with ferrule
- Local Signalling:
- fault indication
- Rohs Exemption Information:
- Yes
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Poles Description:
- 3P
- Tightening Torque:
- 3.5-3.5 N.m bottom
- Color:
- Gray
- Halogen Content Performance:
- Halogen free plastic parts product
- 9 Mm Pitches:
- 7
- [Ue] Rated Operational Voltage:
- 400/415 V AC 50 Hz
- Eu Rohs Directive:
- Compliant with Exemptions
- Environmental Disclosure:
- ENVPEP1409017EN
