Schneider Electric MGA36700 Molded Case Circuit Breaker 600V 700A

(No reviews yet) Write a Review
SKU:
MGA36700
UPC:
785901507512
Condition:
New
Product Name:
PowerPact M
Local Signalling:
1 trip indicator green)
Trip Unit Technology:
electronic, basic, ET 1.0,
Ambient Air Temperature For Operation:
-25-70 °C
Range:
PowerPact
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Ambient Air Temperature For Storage:
-50-85 °C
Control Type:
operating handle
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Circularity Profile:
ENVEOLI2206030EN
Magnetic Tripping Current:
1400-7000 A
Mercury Free:
Yes
Electrical Connection:
I-Line connection, line || lugs, load
Suitability For Isolation:
yes IEC 60947-2
Pvc Free:
Yes
Depth:
8.05 in
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Mounting Mode:
I-Line bracket)
Awg Gauge:
3 x AWG 3/0...3 x 500 kcmil aluminium/copper
Net Weight:
29 lb(US)
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Terminal Identifier:
AL800M23K
Device Application:
distribution
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Circuit Breaker Application:
HACR rated
Breaking Capacity:
AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
Breaking Capacity Code:
G
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
Pollution Degree:
3 IEC 60947-1
Warranty:
18 months
Sustainable Offer Status:
Green Premium product
Poles Description:
3P
Height:
12.86 in
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...3 x 500 kcmil)
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ics] Rated Service Breaking Capacity:
25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
Mounting Support:
bracket
Width:
8.27 in
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Network Frequency:
50/60 Hz
Wire Stripping Length:
25 mm
Eu Rohs Directive:
Compliant with Exemptions
Trip Unit Name:
ET 1.0
Product Or Component Type:
circuit breaker
Rohs Exemption Information:
Yes
Environmental Disclosure:
ENVPEP2206030EN
Continuous Current Rating:
0.8
Quantity Per Set:
1
Ip Degree Of Protection:
IP40
Quality Labels:
CE
Long Time Pick-Up Adjustment Range:
300...800 A
Mounting Height:
9 in
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Line Rated Current:
700-700 A
Utilisation Category:
category A
Color:
Black
Product Certifications:
UL || CSA || NOM
Brochure:
View
Catalog:
View
Datasheet:
View
$10,608.00

Description

PowerPacT M-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version. This circuit breaker has an electronic trip unit, ET 1.0. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT M circuit breakers are available in 2 and 3-pole unit mount or I-Line construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT M, 700A, 3 pole, circuit breaker has an interrupting rating of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT M circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
