Schneider Electric MJL36800SA Molded Case Circuit Breaker 600V 800A

Schneider Electric MJL36800SA Molded Case Circuit Breaker 600V 800A

Schneider Electric
SKU:
MJL36800SA
|
UPC:
7.85901E+11
$12,637.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT M-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version. This circuit breaker has an electronic trip unit, ET 1.0. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT M circuit breakers are available in 2 and 3-pole unit mount or I-Line construction. This unit has lugs on both the line and load sides. This PowerPacT M, 800A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. This unit includes a factory installed 120VAC shunt trip. PowerPacT M circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Wire Stripping Length:
25 mm
Circuit Breaker Application:
HACR rated
Net Weight:
29 lb(US)
Breaking Capacity:
AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Mounting Mode:
unit mount lug)
Poles Description:
3P
Height:
12.86 in
Accessory / Separate Part Type:
shunt trip 24...30 V AC/DC
Depth:
8.05 in
Continuous Current Rating:
0.8
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
Long Time Pick-Up Adjustment Range:
300...800 A
Quantity Per Set:
1
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Terminal Identifier:
AL800M23K
Ambient Air Temperature For Operation:
-25-70 °C
Local Signalling:
1 trip indicator green)
Suitability For Isolation:
yes IEC 60947-2
Line Rated Current:
800-800 A
Ambient Air Temperature For Storage:
-50-85 °C
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Name:
PowerPact M
Awg Gauge:
3 x AWG 3/0...3 x 500 kcmil aluminium/copper
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Magnetic Tripping Current:
1600-8000 A
Color:
Black
Rohs Exemption Information:
Yes
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...3 x 500 kcmil)
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Warranty:
18 months
Circularity Profile:
ENVEOLI2206030EN
Mercury Free:
Yes
Mounting Support:
lug
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Device Application:
distribution
Control Type:
operating handle
[Ics] Rated Service Breaking Capacity:
35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
Ip Degree Of Protection:
IP40
Pvc Free:
Yes
Pollution Degree:
3 IEC 60947-1
Breaking Capacity Code:
J
Width:
8.27 in
Trip Unit Name:
ET 1.0
Product Or Component Type:
circuit breaker
Trip Unit Technology:
electronic, basic, ET 1.0,
Eu Rohs Directive:
Compliant with Exemptions
Electrical Connection:
lugs, load || lugs, line
Quality Labels:
CE
Sustainable Offer Status:
Green Premium product
Product Certifications:
UL || CSA || NOM
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Environmental Disclosure:
ENVPEP2206030EN
Range:
PowerPact
Utilisation Category:
category A
Network Frequency:
50/60 Hz
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
