Schneider Electric MJM36800 Molded Case Circuit Breaker 600V 800A

Schneider Electric MJM36800 Molded Case Circuit Breaker 600V 800A

Schneider Electric
SKU:
MJM36800
|
UPC:
785901422426
Availability:
Contact us to confirm availability and lead times.
$11,882.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT M-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version. This circuit breaker has an electronic trip unit, ET 1.0. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT M circuit breakers are available in 2 and 3-pole unit mount or I-Line construction. This unit has lugs on the line side and terminal nuts on the load side. This PowerPacT M, 800A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT M circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Environmental Disclosure:
ENVPEP2206030EN
Device Application:
distribution
Trip Unit Technology:
electronic, basic, ET 1.0,
Local Signalling:
1 trip indicator green)
Eu Rohs Directive:
Compliant with Exemptions
Height:
12.86 in
Pvc Free:
Yes
Circularity Profile:
ENVEOLI2206030EN
Sustainable Offer Status:
Green Premium product
Awg Gauge:
3 x AWG 3/0...3 x 500 kcmil aluminium/copper
Range:
PowerPact
Pollution Degree:
3 IEC 60947-1
Network Frequency:
50/60 Hz
Rohs Exemption Information:
Yes
Terminal Identifier:
AL800M23K
Mounting Support:
lug
[Ics] Rated Service Breaking Capacity:
35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
Depth:
8.05 in
Product Name:
PowerPact M
Product Certifications:
UL || CSA || NOM
Continuous Current Rating:
0.8
Utilisation Category:
category A
Trip Unit Name:
ET 1.0
Breaking Capacity Code:
J
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...3 x 500 kcmil)
Ip Degree Of Protection:
IP40
Product Or Component Type:
circuit breaker
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Line Rated Current:
800-800 A
Quantity Per Set:
1
Breaking Capacity:
AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Net Weight:
29 lb(US)
Poles Description:
3P
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
Circuit Breaker Application:
HACR rated
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Ambient Air Temperature For Operation:
-25-70 °C
Width:
8.27 in
Color:
Black
Suitability For Isolation:
yes IEC 60947-2
Electrical Connection:
lugs, line || terminal nut, load
Quality Labels:
CE
Mounting Mode:
unit mount lug)
Warranty:
18 months
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Ambient Air Temperature For Storage:
-50-85 °C
Control Type:
operating handle
Magnetic Tripping Current:
1600-8000 A
Mercury Free:
Yes
Long Time Pick-Up Adjustment Range:
300...800 A
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Wire Stripping Length:
25 mm
