Schneider Electric NSYS3X7525 S3X 304L 700X500X250
Schneider Electric
$760.20
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Spacial S3X compact steel enclosure with plain front door. 700 x 500 x 250 mm. Multi-purpose. Installation in wall-mounting. Gutter shaped front rail, single piece body with cross shaped structure. Without mounting plate. Handle double bar 3mm. Body and door stainless steel 304L. Protection IP 55, IK10. Enclosure Scotch-Brite® brushed finish.
- Door Opening Side:
- reversible 120 °)
- Warranty:
- 18 months
- Enclosure Nominal Width:
- 500 mm
- Mounting Plate Description:
- without mounting plate
- Ip Degree Of Protection:
- IP66 IEC 60529
- Enclosure Nominal Depth:
- 250 mm
- Ik Degree Of Protection:
- IK10 IEC 62262
- Removable Parts:
- door by hinges
- Number Of Doors:
- front face 1
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Standards:
- IEC 62208
- Device Application:
- multi-purpose
- Installation Accessory Type:
- wall-mounting
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Environmental Characteristic:
- specific hygiene || corrosive
- Net Weight:
- 17.36 kg
- Accessibility For Operation:
- front
- Product Name:
- Spacial S3X
- Environmental Disclosure:
- ENVPEP2109018EN
- Device Composition:
- 1 body || 1 door || 2 lock door || 2 perforated vertical profile drilled door
- Range:
- Spacial
- Product Or Component Type:
- compact enclosure
- Type Of Gland Plate:
- without gland plate
- Circularity Profile:
- N/A
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Sustainable Offer Status:
- Green Premium product
- Lock Type:
- 2 points lock, 3 mm double-bar
- Body Type:
- single piece body, cross-shaped structure || gutter shaped front rail
- Enclosure Nominal Height:
- 700 mm
- Product Certifications:
- CAN/CSA 22 || UL 508 type A
- Material:
- body and door stainless steel 304L || lock zamak || hinge stainless steel
- Rohs Exemption Information:
- Yes
- Door Type:
- Solid
- Surface Finish:
- body and door Scotch-Brite® brushed || lock chromium plated
- Brochure:
- View
- Datasheet:
- View
