Schneider Electric PGA36080CU33A Molded Case Circuit Breaker 600V 800A

Schneider Electric PGA36080CU33A Molded Case Circuit Breaker 600V 800A

Schneider Electric
SKU:
PGA36080CU33A
|
UPC:
7.85902E+11
$22,794.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Standard with a 5.0 trip unit and an LSI function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 800A, 3 pole, circuit breaker has an interrupting rating of 18kA at 600VAC. This circuit breaker has a continuous current rating of 100% with an ABC phase connection. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Ambient Air Temperature For Storage:
-50-85 °C
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Environmental Disclosure:
ENVPEP2206033EN
Control Type:
toggle
Breaking Capacity Code:
G
Device Application:
distribution
Product Certifications:
UL || CSA || NOM
Ambient Air Temperature For Operation:
-2-70 °C
Width:
8.27 in
[Ics] Rated Service Breaking Capacity:
25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
Pollution Degree:
3 IEC 60947-1
Mounting Height:
9 in
Breaking Capacity:
AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
Electrical Connection:
I-Line connection, line || lugs, load
Continuous Current Rating:
1
Circularity Profile:
ENVEOLI2206033EN
Terminal Identifier:
AL800M23K
Range:
PowerPact
Eu Rohs Directive:
Compliant with Exemptions
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
Mounting Mode:
I-Line bracket)
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Warranty:
18 months
Rohs Exemption Information:
Yes
Product Name:
PowerPact P
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Phase Connection:
ABC
Awg Gauge:
3 x AWG 3/0...500 kcmil aluminium/copper
Long Time Pick-Up Adjustment Range:
0.4...1 x Ir
Local Signalling:
overload 1 1 LED amber) || 1 trip indicator green)
Height:
12.86 in
Pvc Free:
Yes
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Wire Stripping Length:
25 mm
Trip Unit Name:
MicroLogic 5.0
Trip Unit Technology:
electronic, standard, MicroLogic 5.0, LSI
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mercury Free:
Yes
Sustainable Offer Status:
Green Premium product
Poles Description:
3P
Line Rated Current:
800-800 A
Network Frequency:
50/60 Hz
Depth:
8.05 in
Circuit Breaker Application:
HACR rated
Ip Degree Of Protection:
front cover IP40
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Quality Labels:
CE
Quantity Per Set:
1
Net Weight:
32 lb(US)
Mounting Support:
bracket
Product Or Component Type:
circuit breaker
