Schneider Electric PJA36060CU44A Molded Case Circuit Breaker 600V 600A

Schneider Electric PJA36060CU44A Molded Case Circuit Breaker 600V 600A

Schneider Electric
SKU:
PJA36060CU44A
|
UPC:
785901497080
$28,058.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Ammeter with a 6.0A trip unit and an LSIG function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 600A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 100% with an ABC phase connection. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Local Signalling:
1 trip indicator green)
Pollution Degree:
3 IEC 60947-1
Sustainable Offer Status:
Green Premium product
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
Ambient Air Temperature For Operation:
-2-70 °C
Mounting Mode:
I-Line bracket)
Device Application:
distribution
Product Certifications:
UL || CSA || NOM
[Ics] Rated Service Breaking Capacity:
35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
Mercury Free:
Yes
Circuit Breaker Application:
HACR rated
Width:
8.27 in
Control Type:
toggle
Net Weight:
32 lb(US)
Mounting Height:
9 in
Trip Unit Technology:
electronic, ammeter, MicroLogic 6.0 A, LSIG
Range:
PowerPact
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Ambient Air Temperature For Storage:
-50-85 °C
Eu Rohs Directive:
Compliant with Exemptions
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Environmental Disclosure:
ENVPEP2206033EN
Electrical Connection:
I-Line connection, line || lugs, load
Long Time Pick-Up Adjustment Range:
0.4...1 x Ir
Quality Labels:
CE
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Ip Degree Of Protection:
front cover IP40
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Rohs Exemption Information:
Yes
Breaking Capacity:
AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Depth:
8.05 in
Wire Stripping Length:
25 mm
Warranty:
18 months
Network Frequency:
50/60 Hz
Mounting Support:
bracket
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Line Rated Current:
600-600 A
Quantity Per Set:
1
Product Name:
PowerPact P
Poles Description:
3P
Phase Connection:
ABC
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Awg Gauge:
3 x AWG 3/0...500 kcmil aluminium/copper
Terminal Identifier:
AL800M23K
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Height:
12.86 in
Pvc Free:
Yes
Trip Unit Name:
MicroLogic 6.0 A
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Or Component Type:
circuit breaker
Breaking Capacity Code:
J
Continuous Current Rating:
1
Circularity Profile:
ENVEOLI2206033EN
Brochure:
View
Catalog:
View
Datasheet:
View
