Schneider Electric PJA36060U33A Molded Case Circuit Breaker 600V 600A

Schneider Electric PJA36060U33A Molded Case Circuit Breaker 600V 600A

Schneider Electric
SKU:
PJA36060U33A
|
UPC:
785901886594
Availability:
Contact us to confirm availability and lead times.
$16,608.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Standard with a 5.0 trip unit and an LSI function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 600A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Mounting Height:
9 in
Trip Unit Technology:
electronic, standard, MicroLogic 5.0, LSI
Long Time Pick-Up Adjustment Range:
0.4...1 x Ir
Product Or Component Type:
circuit breaker
Mercury Free:
Yes
Sustainable Offer Status:
Green Premium product
Quality Labels:
CE
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Continuous Current Rating:
0.8
Depth:
8.05 in
Height:
12.86 in
Environmental Disclosure:
ENVPEP2206033EN
Electrical Connection:
I-Line connection, line || lugs, load
Control Type:
toggle
Trip Unit Name:
MicroLogic 5.0
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Breaking Capacity Code:
J
Poles Description:
3P
Mounting Support:
bracket
Line Rated Current:
600-600 A
[Ics] Rated Service Breaking Capacity:
35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
Network Frequency:
50/60 Hz
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Product Certifications:
UL || CSA || NOM
Warranty:
18 months
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Ip Degree Of Protection:
front cover IP40
Rohs Exemption Information:
Yes
Phase Connection:
ABC
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
Terminal Identifier:
AL800M23K
Range:
PowerPact
Awg Gauge:
3 x AWG 3/0...500 kcmil aluminium/copper
Device Application:
distribution
Quantity Per Set:
1
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Wire Stripping Length:
25 mm
Ambient Air Temperature For Operation:
-2-70 °C
Breaking Capacity:
AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Local Signalling:
1 trip indicator green)
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Product Name:
PowerPact P
Pollution Degree:
3 IEC 60947-1
Net Weight:
32 lb(US)
Circularity Profile:
ENVEOLI2206033EN
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Width:
8.27 in
Mounting Mode:
I-Line bracket)
Eu Rohs Directive:
Compliant with Exemptions
Ambient Air Temperature For Storage:
-50-85 °C
Pvc Free:
Yes
Circuit Breaker Application:
HACR rated
