Schneider Electric PJA36080CU31A Molded Case Circuit Breaker 600V 800A

Schneider Electric PJA36080CU31A Molded Case Circuit Breaker 600V 800A

Schneider Electric
SKU:
PJA36080CU31A
|
UPC:
7.85901E+11
$23,897.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Standard with a 3.0 trip unit and an LI function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 800A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 100% with an ABC phase connection. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Product Certifications:
UL || CSA || NOM
Ambient Air Temperature For Operation:
-2-70 °C
Circularity Profile:
ENVEOLI2206033EN
Wire Stripping Length:
25 mm
Mounting Mode:
I-Line bracket)
Sustainable Offer Status:
Green Premium product
Phase Connection:
ABC
Line Rated Current:
800-800 A
Quality Labels:
CE
Breaking Capacity Code:
J
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Electrical Connection:
I-Line connection, line || lugs, load
Ambient Air Temperature For Storage:
-50-85 °C
Environmental Disclosure:
ENVPEP2206033EN
Quantity Per Set:
1
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Terminal Identifier:
AL800M23K
Network Frequency:
50/60 Hz
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Control Type:
toggle
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Trip Unit Technology:
electronic, standard, MicroLogic 3.0, LI
Mounting Support:
bracket
[Ics] Rated Service Breaking Capacity:
35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
Range:
PowerPact
Depth:
8.05 in
Mounting Height:
9 in
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Continuous Current Rating:
1
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Trip Unit Name:
MicroLogic 3.0
Warranty:
18 months
Product Or Component Type:
circuit breaker
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Pvc Free:
Yes
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
Height:
12.86 in
Mercury Free:
Yes
Device Application:
distribution
Net Weight:
32 lb(US)
Eu Rohs Directive:
Compliant with Exemptions
Long Time Pick-Up Adjustment Range:
0.4...1 x Ir
Product Name:
PowerPact P
Local Signalling:
overload 1 1 LED amber) || 1 trip indicator green)
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information:
Yes
Pollution Degree:
3 IEC 60947-1
Awg Gauge:
3 x AWG 3/0...500 kcmil aluminium/copper
Width:
8.27 in
Breaking Capacity:
AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Circuit Breaker Application:
HACR rated
Ip Degree Of Protection:
front cover IP40
Poles Description:
3P
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Brochure:
View
Catalog:
View
Datasheet:
View
