Schneider Electric PLA34120 Molded Case Circuit Breaker 480V 1200A

Schneider Electric PLA34120 Molded Case Circuit Breaker 480V 1200A

Schneider Electric
SKU:
PLA34120
|
UPC:
785901497318
$22,410.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has an electronic trip unit, ET 1.0I. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 1200A, 3 pole, circuit breaker has an interrupting rating of 100kA at 480VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Electrical Connection:
I-Line connection, line || lugs, load
Device Application:
distribution
Product Or Component Type:
circuit breaker
Line Rated Current:
1200-1200 A
Phase Connection:
ABC
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Name:
PowerPact P
Long Time Pick-Up Adjustment Range:
1 In
Sustainable Offer Status:
Green Premium product
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Depth:
8.05 in
Poles Description:
3P
Width:
8.27 in
Quantity Per Set:
1
Rohs Exemption Information:
Yes
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Warranty:
18 months
Product Certifications:
UL || CSA || NOM
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Trip Unit Technology:
electronic, basic, ET 1.0I, I
Eu Rohs Directive:
Compliant with Exemptions
Net Weight:
32 lb(US)
Height:
16.16 in
Ambient Air Temperature For Storage:
-50-85 °C
Breaking Capacity Code:
L
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Tightening Torque:
50-50 N.m 95-240 mm² (4 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
Local Signalling:
1 trip indicator green)
Mounting Support:
bracket
Environmental Disclosure:
ENVPEP2206033EN
Mounting Height:
9 in
Range:
PowerPact
Ambient Air Temperature For Operation:
-2-70 °C
[Ue] Rated Operational Voltage:
480 V AC 50/60 Hz UL 489
Pvc Free:
Yes
Awg Gauge:
4 x AWG 3/0...500 kcmil aluminium/copper
Wire Stripping Length:
30 mm
Quality Labels:
CE
Breaking Capacity:
AIR 125 kA 240 V AC 50/60 Hz UL 489 || AIR 100 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 125 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 85 kA 380/415 V AC 50/60 Hz IEC 60947-2
Mounting Mode:
I-Line bracket)
[Ics] Rated Service Breaking Capacity:
65 kA 240 V AC 50/60 Hz IEC 60947-2 || 45 kA 380/415 V AC 50/60 Hz IEC 60947-2
Terminal Identifier:
AL1200P25K
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Circularity Profile:
ENVEOLI2206033EN
Circuit Breaker Application:
HACR rated
Control Type:
toggle
Pollution Degree:
3 IEC 60947-1
Trip Unit Name:
ET 1.0I
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Ip Degree Of Protection:
front cover IP40
Continuous Current Rating:
0.8
Mercury Free:
Yes
Network Frequency:
50/60 Hz
