Schneider Electric PLA34120U44A Molded Case Circuit Breaker 480V 1200A

Schneider Electric PLA34120U44A Molded Case Circuit Breaker 480V 1200A

Schneider Electric
SKU:
PLA34120U44A
|
UPC:
7.85901E+11
$27,416.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Ammeter with a 6.0A trip unit and an LSIG function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 1200A, 3 pole, circuit breaker has an interrupting rating of 100kA at 480VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Awg Gauge:
4 x AWG 3/0...500 kcmil aluminium/copper
Quality Labels:
CE
Product Or Component Type:
circuit breaker
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Line Rated Current:
1200-1200 A
Height:
16.16 in
Warranty:
18 months
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Ambient Air Temperature For Operation:
-2-70 °C
Device Application:
distribution
Long Time Pick-Up Adjustment Range:
0.4...1 x Ir
Ip Degree Of Protection:
front cover IP40
Mounting Mode:
I-Line bracket)
Trip Unit Name:
MicroLogic 6.0 A
Quantity Per Set:
1
Phase Connection:
ABC
Pvc Free:
Yes
Local Signalling:
overload 1 1 LED amber) || 1 flag green) || trip causes 4 trip indicator red)
Ambient Air Temperature For Storage:
-50-85 °C
Control Type:
toggle
Net Weight:
32 lb(US)
Mounting Support:
bracket
Terminal Identifier:
AL1200P25K
Circuit Breaker Application:
HACR rated
Eu Rohs Directive:
Compliant with Exemptions
Rohs Exemption Information:
Yes
Tightening Torque:
50-50 N.m 95-240 mm² (4 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
Continuous Current Rating:
0.8
Breaking Capacity:
AIR 125 kA 240 V AC 50/60 Hz UL 489 || AIR 100 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 125 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 85 kA 380/415 V AC 50/60 Hz IEC 60947-2
Sustainable Offer Status:
Green Premium product
Depth:
8.05 in
Trip Unit Technology:
electronic, ammeter, MicroLogic 6.0 A, LSIG
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Environmental Disclosure:
ENVPEP2206033EN
Width:
8.27 in
Range:
PowerPact
Mounting Height:
9 in
[Ics] Rated Service Breaking Capacity:
65 kA 240 V AC 50/60 Hz IEC 60947-2 || 45 kA 380/415 V AC 50/60 Hz IEC 60947-2
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Product Certifications:
UL || CSA || NOM
Pollution Degree:
3 IEC 60947-1
[Ue] Rated Operational Voltage:
480 V AC 50/60 Hz UL 489
Wire Stripping Length:
30 mm
Network Frequency:
50/60 Hz
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Electrical Connection:
I-Line connection, line || lugs, load
Product Name:
PowerPact P
Circularity Profile:
ENVEOLI2206033EN
Breaking Capacity Code:
L
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Poles Description:
3P
Mercury Free:
Yes
