Schneider Electric QHB125 Miniature Circuit Breaker 120/240V 25A
Schneider Electric
$122.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QHB125 Miniature Circuit Breaker 120/240V 25A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 25A at 120/240VAC. This unit provides 65kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Breaking Capacity:
- 65 kA 120/240 V AC 50/60 Hz || 65 kA 120 V AC 50/60 Hz
- Range Of Product:
- QO
- Mounting Mode:
- bolt-on
- Circuit Breaker Application:
- HACR rated
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Rohs Exemption Information:
- Yes
- Line Rated Current:
- 25 A
- Toxic Heavy Metal Free:
- Yes
- Depth:
- 74 mm
- Product Certifications:
- UL Listed || CSA
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Warranty:
- 18 months
- Ambient Air Temperature For Operation:
- 40 °C
- Product Or Component Type:
- miniature circuit-breaker
- Poles Description:
- 1P
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
- Width:
- 19 mm
- Number Of Spaces Required:
- 1
- Net Weight:
- 0.136 kg
- Mercury Free:
- Yes
- Circuit Breaker Type:
- standard
- Height:
- 76 mm
- Electrical Connection:
- pressure plate
- Eu Rohs Directive:
- Compliant with Exemptions
- Tightening Torque:
- 4.6-4.6 N.m
