Schneider Electric QHB225 Miniature Circuit Breaker 120/240V 25A.
Schneider Electric
$342.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QHB225 Miniature Circuit Breaker 120/240V 25A.
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 25A at 120/240VAC. This unit provides 65kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Circuit Breaker Application:
- HACR rated
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
- Warranty:
- 18 months
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Range Of Product:
- QO
- Mounting Mode:
- bolt-on
- Tightening Torque:
- 4.6-4.6 N.m
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Compliant with Exemptions
- Depth:
- 74 mm
- Width:
- 38 mm
- Net Weight:
- 0.277 kg
- Ambient Air Temperature For Operation:
- 40 °C
- Line Rated Current:
- 25 A
- Sustainable Offer Status:
- Green Premium product
- Rohs Exemption Information:
- Yes
- Toxic Heavy Metal Free:
- Yes
- Halogen Content Performance:
- Halogen free product
- Breaking Capacity:
- 65 kA 120/240 V AC 50/60 Hz || 65 kA 120 V AC 50/60 Hz
- Poles Description:
- 2P
- Height:
- 76 mm
- Circuit Breaker Type:
- standard
- Product Certifications:
- UL Listed || CSA
- Number Of Spaces Required:
- 2
- Product Or Component Type:
- miniature circuit-breaker
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Electrical Connection:
- pressure plate
- Circularity Profile:
- N/A
