Schneider Electric QOB11535 Miniature Circuit Breaker 120/240V 15A
Schneider Electric
$71.55
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB11535 Miniature Circuit Breaker 120/240V 15A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 15A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product is rated for operation at 50 degrees C. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Ambient Air Temperature For Operation:
- 50 °C
- Tightening Torque:
- 4-4 N.m
- Number Of Spaces Required:
- 1
- Circuit Breaker Application:
- HACR rated
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Mercury Free:
- Yes
- Electrical Connection:
- pressure plate
- Warranty:
- 18 months
- Width:
- 19 mm
- Product Or Component Type:
- miniature circuit-breaker
- Range Of Product:
- QO
- Sustainable Offer Status:
- Green Premium product
- Depth:
- 74 mm
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Toxic Heavy Metal Free:
- Yes
- Circuit Breaker Type:
- standard
- Halogen Content Performance:
- Halogen free product
- Net Weight:
- 0.132 kg
- Eu Rohs Directive:
- Compliant with Exemptions
- Rohs Exemption Information:
- Yes
- Mounting Mode:
- bolt-on
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Poles Description:
- 1P
- Line Rated Current:
- 15 A
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Circularity Profile:
- N/A
- Height:
- 76 mm
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
