Schneider Electric QOB115HM Miniature Circuit Breaker 120/240V 15A

(No reviews yet) Write a Review
SKU:
QOB115HM
UPC:
7.85901E+11
Condition:
New
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Net Weight:
0.145 kg
Halogen Content Performance:
Halogen free product
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Circuit Breaker Application:
HACR and Switching Duty rated
Tightening Torque:
4-4 N.m
Circularity Profile:
N/A
Line Rated Current:
15 A
Product Or Component Type:
miniature circuit-breaker
Ambient Air Temperature For Operation:
40 °C
Depth:
74 mm
Range Of Product:
QO
Circuit Breaker Type:
high magnetic
Warranty:
18 months
Sustainable Offer Status:
Green Premium product
Eu Rohs Directive:
Compliant with Exemptions
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Certifications:
UL Listed || CSA
Height:
76 mm
Awg Gauge:
AWG 14...AWG 8 copper or aluminium
Rohs Exemption Information:
Yes
Toxic Heavy Metal Free:
Yes
Poles Description:
1P
Breaking Capacity:
10 kA 120/240 V AC 50/60 Hz
Width:
19 mm
Mounting Mode:
bolt-on
[Ue] Rated Operational Voltage:
120/240 V AC
Electrical Connection:
pressure plate
Number Of Spaces Required:
1
Mercury Free:
Yes
Brochure:
View
Catalog:
View
Datasheet:
View
  • Schneider Electric QOB115HM Miniature Circuit Breaker 120/240V 15A
  • Schneider Electric QOB115HM Miniature Circuit Breaker 120/240V 15A
$39.80

Description

QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 15A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product has a high magnetic feature. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
