Schneider Electric QOB1201200FT Miniature Circuit Breaker 120/240V 20A

(No reviews yet) Write a Review
SKU:
QOB1201200FT
UPC:
3606486144299
Condition:
New
Circuit Breaker Type:
standard
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Ambient Air Temperature For Operation:
40 °C
Number Of Spaces Required:
2
Poles Description:
1P
Net Weight:
0.386 kg
Awg Gauge:
AWG 14...AWG 8 copper or aluminium
Height:
76 mm
Width:
38 mm
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Product Or Component Type:
miniature circuit-breaker
Electrical Connection:
pressure plate
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information:
Yes
Range Of Product:
QO
Tightening Torque:
4-4 N.m
Line Rated Current:
20 A
Mercury Free:
Yes
Circuit Breaker Application:
HACR and Switching Duty rated
Eu Rohs Directive:
Compliant with Exemptions
Depth:
74 mm
[Ue] Rated Operational Voltage:
120/240 V AC || 120 V AC
Mounting Mode:
bolt-on
Accessory / Separate Part Type:
auxiliary switch 120 V AC 1A
Product Certifications:
UL Listed || CSA
Breaking Capacity:
10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
Toxic Heavy Metal Free:
Yes
Brochure:
View
Datasheet:
View
$179.80

Description

QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 20A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an auxiliary switch 1A and fungal treatment. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
