Schneider Electric QOB120VHGFI Miniature Circuit Breaker 120V 20A
Schneider Electric
$497.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB120VHGFI Miniature Circuit Breaker 120V 20A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 20A at 120VAC. This unit provides 22kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a 6mA ground fault A with pigtail. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Depth:
- 74 mm
- Eu Rohs Directive:
- Compliant with Exemptions
- Height:
- 105 mm
- Halogen Content Performance:
- Halogen free product
- Awg Gauge:
- AWG 14...AWG 8 copper || AWG 12...AWG 8 aluminium
- Tightening Torque:
- 4.6-4.6 N.m 2.5-10 mm² (AWG 16...AWG 14) || 4.6-4.6 N.m 4-20 mm² (AWG 12...AWG 4)
- Width:
- 19 mm
- Ambient Air Temperature For Operation:
- 40 °C
- Range Of Product:
- QO
- Warranty:
- 18 months
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Mounting Mode:
- bolt-on
- Number Of Spaces Required:
- 1
- Circularity Profile:
- N/A
- Circuit Breaker Application:
- not rated
- [Ue] Rated Operational Voltage:
- 120 V AC
- Mercury Free:
- Yes
- Rohs Exemption Information:
- Yes
- Net Weight:
- 0.227 kg
- Toxic Heavy Metal Free:
- Yes
- Product Certifications:
- UL Listed || CSA
- Sustainable Offer Status:
- Green Premium product
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Poles Description:
- 1P
- Electrical Connection:
- pressure plate
- Breaking Capacity:
- 22 kA 120 V AC 50/60 Hz
- Line Rated Current:
- 20 A
- Product Or Component Type:
- miniature circuit-breaker
- Circuit Breaker Type:
- ground fault protecting class A 6 mA
