Schneider Electric QOB130HID Miniature Circuit Breaker 120/240V 30A

Schneider Electric QOB130HID Miniature Circuit Breaker 120/240V 30A

Schneider Electric
SKU:
QOB130HID
|
UPC:
7.85901E+11
Availability:
Contact us to confirm availability and lead times.
$49.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product has a high density discharge feature. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
Additional Information
Mercury Free:
Yes
Halogen Content Performance:
Halogen free product
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Awg Gauge:
AWG 14...AWG 8 copper or aluminium
Poles Description:
1P
Number Of Spaces Required:
1
California Proposition 65:
WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Width:
19 mm
Tightening Torque:
4-4 N.m
Product Certifications:
UL Listed || CSA
Net Weight:
0.136 kg
Depth:
74 mm
Rohs Exemption Information:
Yes
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Mounting Mode:
bolt-on
Sustainable Offer Status:
Green Premium product
Product Or Component Type:
miniature circuit-breaker
Breaking Capacity:
10 kA 120/240 V AC 50/60 Hz
Ambient Air Temperature For Operation:
40 °C
Eu Rohs Directive:
Compliant with Exemptions
Height:
76 mm
Circularity Profile:
N/A
Circuit Breaker Application:
not rated
Electrical Connection:
pressure plate
[Ue] Rated Operational Voltage:
120/240 V AC
Line Rated Current:
30 A
Range Of Product:
QO
Warranty:
18 months
Circuit Breaker Type:
high intensity discharge
