Schneider Electric QOB21101021 Miniature Circuit Breaker 120/240V 110A

(No reviews yet) Write a Review
SKU:
QOB21101021
UPC:
3606486144565
Condition:
New
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Net Weight:
0.463 kg
Poles Description:
2P
Circuit Breaker Type:
standard
Product Certifications:
UL Listed || CSA
[Ue] Rated Operational Voltage:
120/240 V AC || 120 V AC
Mercury Free:
Yes
Height:
89 mm
Width:
57 mm
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Or Component Type:
miniature circuit-breaker
Rohs Exemption Information:
Yes
Depth:
74 mm
Ambient Air Temperature For Operation:
40 °C
Line Rated Current:
110 A
Accessory / Separate Part Type:
shunt trip 120/208/240 V AC
Electrical Connection:
box lugs
Mounting Mode:
bolt-on
Breaking Capacity:
10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
Tightening Torque:
5.6-5.6 N.m
Awg Gauge:
AWG 4...AWG 2/0 copper or aluminium
Range Of Product:
QO
Circuit Breaker Application:
HACR rated
Warranty:
18 months
Eu Rohs Directive:
Compliant with Exemptions
Number Of Spaces Required:
3
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
$690.00

Description

QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 110A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
