Schneider Electric QOB220H35 Miniature Circuit Breaker 240V 20A

(No reviews yet) Write a Review

Write a Review

Schneider Electric QOB220H35 Miniature Circuit Breaker 240V 20A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

QOB220H35

UPC:

3606486144688

MPN:

Condition:

New

Depth:

74 mm

Eu Rohs Directive:

Compliant with Exemptions

Electrical Connection:

pressure plate

Range Of Product:

QO

Ambient Air Temperature For Operation:

50 °C

Awg Gauge:

AWG 14...AWG 8 copper or aluminium

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Rohs Exemption Information:

Yes

Number Of Spaces Required:

2

[Ue] Rated Operational Voltage:

120/240 V AC || 240 V AC || 120 V AC

Circuit Breaker Type:

standard

Circuit Breaker Application:

HACR rated

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Tightening Torque:

4.6-4.6 N.m

Toxic Heavy Metal Free:

Yes

Mounting Mode:

bolt-on

Poles Description:

2P

Line Rated Current:

20 A

Breaking Capacity:

10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz

Product Or Component Type:

miniature circuit-breaker

Warranty:

18 months

Net Weight:

0.277 kg

Width:

38 mm

Mercury Free:

Yes

Height:

76 mm

California Proposition 65:

WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov

Product Certifications:

UL Listed || CSA

Brochure:

View

Datasheet:

View
