Schneider Electric QOB220VH1042 Miniature Circuit Breaker 240V 20A

(No reviews yet) Write a Review

Write a Review

Schneider Electric QOB220VH1042 Miniature Circuit Breaker 240V 20A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

QOB220VH1042

UPC:

3.60649E+12

MPN:

Condition:

New

Breaking Capacity:

22 kA 120/240 V AC 50/60 Hz || 22 kA 240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz

Net Weight:

0.485 kg

Line Rated Current:

20 A

Ambient Air Temperature For Operation:

40 °C

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Tightening Torque:

4.6-4.6 N.m

Depth:

74 mm

Poles Description:

2P

Electrical Connection:

pressure plate

Warranty:

18 months

Rohs Exemption Information:

Yes

Range Of Product:

QO

Product Or Component Type:

miniature circuit-breaker

Mounting Mode:

bolt-on

Circuit Breaker Application:

HACR rated

Toxic Heavy Metal Free:

Yes

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Mercury Free:

Yes

Accessory / Separate Part Type:

shunt trip 12/24 V AC/DC

Eu Rohs Directive:

Compliant with Exemptions

Height:

76 mm

Awg Gauge:

AWG 14...AWG 8 copper or aluminium

[Ue] Rated Operational Voltage:

120/240 V AC || 240 V AC || 120 V AC

Product Certifications:

UL Listed || CSA

Number Of Spaces Required:

3

Width:

57 mm

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Circuit Breaker Type:

standard
