Schneider Electric QOB22535 Miniature Circuit Breaker 120/240V 25A
Schneider Electric
$107.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB22535 Miniature Circuit Breaker 120/240V 25A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 25A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product is rated for operation at 50 degrees C. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Warranty:
- 18 months
- Electrical Connection:
- pressure plate
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Circuit Breaker Application:
- HACR rated
- Number Of Spaces Required:
- 2
- Toxic Heavy Metal Free:
- Yes
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Tightening Torque:
- 4-4 N.m
- Product Certifications:
- UL Listed || CSA
- Range Of Product:
- QO
- Sustainable Offer Status:
- Green Premium product
- Mounting Mode:
- bolt-on
- Width:
- 38 mm
- Poles Description:
- 2P
- Depth:
- 74 mm
- Ambient Air Temperature For Operation:
- 50 °C
- Circularity Profile:
- N/A
- Mercury Free:
- Yes
- Product Or Component Type:
- miniature circuit-breaker
- Circuit Breaker Type:
- standard
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Net Weight:
- 0.268 kg
- Rohs Exemption Information:
- Yes
- Halogen Content Performance:
- Halogen free product
- Eu Rohs Directive:
- Compliant with Exemptions
- Line Rated Current:
- 25 A
- Height:
- 76 mm
