Schneider Electric QOB23035 Miniature Circuit Breaker 120/240V 30A

Schneider Electric QOB23035 Miniature Circuit Breaker 120/240V 30A

Schneider Electric
SKU:
QOB23035
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$107.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product is rated for operation at 50 degrees C. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
Additional Information
Circularity Profile:
N/A
Electrical Connection:
pressure plate
Range Of Product:
QO
Warranty:
18 months
Rohs Exemption Information:
Yes
Circuit Breaker Application:
HACR rated
Mercury Free:
Yes
Circuit Breaker Type:
standard
Line Rated Current:
30 A
Number Of Spaces Required:
2
Poles Description:
2P
Product Or Component Type:
miniature circuit-breaker
Mounting Mode:
bolt-on
Tightening Torque:
4-4 N.m
Product Certifications:
UL Listed || CSA
Toxic Heavy Metal Free:
Yes
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ue] Rated Operational Voltage:
120/240 V AC || 120 V AC
Awg Gauge:
AWG 14...AWG 8 copper or aluminium
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Sustainable Offer Status:
Green Premium product
Net Weight:
0.277 kg
Depth:
74 mm
Halogen Content Performance:
Halogen free product
Height:
76 mm
Breaking Capacity:
10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
Ambient Air Temperature For Operation:
50 °C
Width:
38 mm
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Eu Rohs Directive:
Compliant with Exemptions
Brochure:
View
Catalog:
View
Datasheet:
View
