Schneider Electric QOB230SWN Miniature Circuit Breaker 120V 30A
Schneider Electric
$116.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB230SWN Miniature Circuit Breaker 120V 30A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 30A at 120VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a switch neutral. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Tightening Torque:
- 4-4 N.m
- Height:
- 76 mm
- Poles Description:
- 2P
- Electrical Connection:
- pressure plate
- Width:
- 38 mm
- Warranty:
- 18 months
- Circuit Breaker Type:
- switch neutral
- Circuit Breaker Application:
- not rated
- Breaking Capacity:
- 10 kA 120 V AC 50/60 Hz
- Rohs Exemption Information:
- Yes
- [Ue] Rated Operational Voltage:
- 120 V AC
- Halogen Content Performance:
- Halogen free product
- Eu Rohs Directive:
- Compliant with Exemptions
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Product Or Component Type:
- miniature circuit-breaker
- Ambient Air Temperature For Operation:
- 40 °C
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Range Of Product:
- QO
- Mercury Free:
- Yes
- Mounting Mode:
- bolt-on
- Number Of Spaces Required:
- 2
- Product Certifications:
- UL Listed || CSA
- Line Rated Current:
- 30 A
- Circularity Profile:
- N/A
- Toxic Heavy Metal Free:
- Yes
- Net Weight:
- 0.286 kg
- Depth:
- 74 mm
- Sustainable Offer Status:
- Green Premium product
