Schneider Electric QOB24035 Miniature Circuit Breaker 120/240V 40A
Schneider Electric
$107.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB24035 Miniature Circuit Breaker 120/240V 40A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 40A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product is rated for operation at 50 degrees C. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Eu Rohs Directive:
- Compliant with Exemptions
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Product Certifications:
- UL Listed || CSA
- Number Of Spaces Required:
- 2
- Depth:
- 74 mm
- Circularity Profile:
- N/A
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Toxic Heavy Metal Free:
- Yes
- Product Or Component Type:
- miniature circuit-breaker
- Width:
- 38 mm
- Range Of Product:
- QO
- Mercury Free:
- Yes
- Halogen Content Performance:
- Halogen free product
- Circuit Breaker Type:
- standard
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Height:
- 79 mm
- Ambient Air Temperature For Operation:
- 50 °C
- Warranty:
- 18 months
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Sustainable Offer Status:
- Green Premium product
- Net Weight:
- 0.277 kg
- Poles Description:
- 2P
- Awg Gauge:
- AWG 8...AWG 2 copper or aluminium
- Line Rated Current:
- 40 A
- Tightening Torque:
- 5-5 N.m
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
- Mounting Mode:
- bolt-on
- Rohs Exemption Information:
- Yes
- Circuit Breaker Application:
- HACR rated
- Electrical Connection:
- box lugs
