Schneider Electric

Schneider Electric QOB240VH1021 Miniature Circuit Breaker 240V 40A

(No reviews yet) Write a Review
SKU:
QOB240VH1021
UPC:
785901731924
Condition:
New
[Ue] Rated Operational Voltage:
120/240 V AC || 240 V AC || 120 V AC
Awg Gauge:
AWG 8...AWG 2 copper or aluminium
Circuit Breaker Application:
HACR rated
Rohs Exemption Information:
Yes
Product Or Component Type:
miniature circuit-breaker
Mounting Mode:
bolt-on
Number Of Spaces Required:
3
Ambient Air Temperature For Operation:
40 °C
Range Of Product:
QO
Sustainable Offer Status:
Green Premium product
Poles Description:
2P
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Breaking Capacity:
22 kA 120/240 V AC 50/60 Hz || 22 kA 240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz
Width:
57 mm
Electrical Connection:
box lugs
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Line Rated Current:
40 A
Circularity Profile:
N/A
Net Weight:
0.454 kg
Tightening Torque:
5.6-5.6 N.m
Eu Rohs Directive:
Compliant with Exemptions
Mercury Free:
Yes
Accessory / Separate Part Type:
shunt trip 120/208/240 V AC
Halogen Content Performance:
Halogen free product
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Depth:
74 mm
Height:
79 mm
Warranty:
18 months
Circuit Breaker Type:
standard
Product Certifications:
UL Listed || CSA
Brochure:
View
Catalog:
View
Datasheet:
View
$360.00

Description

QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 40A at 240VAC. This unit provides 22kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
