Schneider Electric QOB2601021 Miniature Circuit Breaker 120/240V 60A
Schneider Electric
$278.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB2601021 Miniature Circuit Breaker 120/240V 60A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 60A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Awg Gauge:
- AWG 8...AWG 2 copper or aluminium
- Line Rated Current:
- 60 A
- Circularity Profile:
- N/A
- Mercury Free:
- Yes
- Depth:
- 74 mm
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Height:
- 79 mm
- Number Of Spaces Required:
- 3
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
- Sustainable Offer Status:
- Green Premium product
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Circuit Breaker Type:
- standard
- Accessory / Separate Part Type:
- shunt trip 120/208/240 V AC
- Product Or Component Type:
- miniature circuit-breaker
- Electrical Connection:
- box lugs
- Net Weight:
- 0.435 kg
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Eu Rohs Directive:
- Compliant with Exemptions
- Tightening Torque:
- 5-5 N.m
- Rohs Exemption Information:
- Yes
- Halogen Content Performance:
- Halogen free product
- Warranty:
- 18 months
- Ambient Air Temperature For Operation:
- 40 °C
- Mounting Mode:
- bolt-on
- Width:
- 57 mm
- Poles Description:
- 2P
- Range Of Product:
- QO
- Toxic Heavy Metal Free:
- Yes
- Circuit Breaker Application:
- HACR rated
- Product Certifications:
- UL Listed || CSA
