Schneider Electric QOB315FT Miniature Circuit Breaker 240V 15A

Schneider Electric QOB315FT Miniature Circuit Breaker 240V 15A

Schneider Electric
SKU:
QOB315FT
|
UPC:
785901085768
Availability:
Contact us to confirm availability and lead times.
$351.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 15A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a fungal treatment. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
Additional Information
Sustainable Offer Status:
Green Premium product
Width:
57 mm
Electrical Connection:
pressure plate
Mercury Free:
Yes
Poles Description:
3P
Height:
105 mm
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Tightening Torque:
4-4 N.m
Range Of Product:
QO
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Awg Gauge:
AWG 14...AWG 8 copper or aluminium
Number Of Spaces Required:
3
Eu Rohs Directive:
Compliant with Exemptions
Toxic Heavy Metal Free:
Yes
Mounting Mode:
bolt-on
Warranty:
18 months
Halogen Content Performance:
Halogen free product
Product Or Component Type:
miniature circuit-breaker
Breaking Capacity:
10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
Product Certifications:
UL Listed || CSA
Rohs Exemption Information:
Yes
Line Rated Current:
15 A
Circularity Profile:
N/A
[Ue] Rated Operational Voltage:
120/240 V AC || 240 V AC || 120 V AC
Net Weight:
0.395 kg
Circuit Breaker Application:
HACR rated
Depth:
74 mm
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Ambient Air Temperature For Operation:
40 °C
Brochure:
View
Datasheet:
View
