Schneider Electric QOB315SWN Miniature Circuit Breaker 240V 15A
Schneider Electric
$255.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB315SWN Miniature Circuit Breaker 240V 15A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 15A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a switch neutral. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Poles Description:
- 3P
- Toxic Heavy Metal Free:
- Yes
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Sustainable Offer Status:
- Green Premium product
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz
- [Ue] Rated Operational Voltage:
- 120/240 V AC
- Electrical Connection:
- pressure plate
- Eu Rohs Directive:
- Compliant with Exemptions
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Warranty:
- 18 months
- Rohs Exemption Information:
- Yes
- Height:
- 76 mm
- Net Weight:
- 0.413 kg
- Circuit Breaker Application:
- not rated
- Circuit Breaker Type:
- switch neutral
- Product Certifications:
- UL Listed || CSA
- Ambient Air Temperature For Operation:
- 40 °C
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Line Rated Current:
- 15 A
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Product Or Component Type:
- miniature circuit-breaker
- Mercury Free:
- Yes
- Depth:
- 74 mm
- Number Of Spaces Required:
- 3
- Tightening Torque:
- 4-4 N.m
- Mounting Mode:
- bolt-on
- Halogen Content Performance:
- Halogen free product
- Range Of Product:
- QO
- Width:
- 57 mm
- Circularity Profile:
- N/A
