Schneider Electric QOB320VH1021 Miniature Circuit Breaker 240V 20A
Schneider Electric
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 20A at 120/240VAC. This unit provides 22kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Number Of Spaces Required:
- 4
- Tightening Torque:
- 4.6-4.6 N.m
- Product Certifications:
- UL Listed || CSA
- Range Of Product:
- QO
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Warranty:
- 18 months
- Width:
- 76 mm
- Electrical Connection:
- pressure plate
- Depth:
- 74 mm
- Rohs Exemption Information:
- Yes
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Breaking Capacity:
- 22 kA 120/240 V AC 50/60 Hz || 22 kA 240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz
- Circuit Breaker Application:
- HACR rated
- Ambient Air Temperature For Operation:
- 40 °C
- Mercury Free:
- Yes
- Circularity Profile:
- N/A
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Mounting Mode:
- bolt-on
- Halogen Content Performance:
- Halogen free product
- Line Rated Current:
- 20 A
- Product Or Component Type:
- miniature circuit-breaker
- Net Weight:
- 0.549 kg
- Height:
- 76 mm
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC
- Sustainable Offer Status:
- Green Premium product
- Accessory / Separate Part Type:
- shunt trip 120/208/240 V AC
- Circuit Breaker Type:
- standard
- Poles Description:
- 3P
- Eu Rohs Directive:
- Compliant with Exemptions
- Toxic Heavy Metal Free:
- Yes
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
