Schneider Electric QOB3301042 Miniature Circuit Breaker 240V 30A

(No reviews yet) Write a Review
SKU:
QOB3301042
UPC:
785901907930
Condition:
New
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ue] Rated Operational Voltage:
120/240 V AC || 240 V AC || 120 V AC
Line Rated Current:
30 A
Ambient Air Temperature For Operation:
40 °C
Sustainable Offer Status:
Green Premium product
Height:
76 mm
Depth:
74 mm
Mercury Free:
Yes
Poles Description:
3P
Number Of Spaces Required:
4
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Circuit Breaker Type:
standard
Circularity Profile:
N/A
Toxic Heavy Metal Free:
Yes
Awg Gauge:
AWG 14...AWG 8 copper or aluminium
Electrical Connection:
pressure plate
Range Of Product:
QO
Circuit Breaker Application:
HACR rated
Rohs Exemption Information:
Yes
Halogen Content Performance:
Halogen free product
Warranty:
18 months
Mounting Mode:
bolt-on
Breaking Capacity:
10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
Accessory / Separate Part Type:
shunt trip 12/24 V AC/DC
Net Weight:
0.549 kg
Width:
76 mm
Product Or Component Type:
miniature circuit-breaker
Tightening Torque:
4-4 N.m
Product Certifications:
UL Listed || CSA
Eu Rohs Directive:
Compliant with Exemptions
Brochure:
View
Datasheet:
View
$482.00

Description

QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC/DC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
