Schneider Electric QOB340VH1042 Miniature Circuit Breaker 240V 40A
Schneider Electric
$629.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 40A at 120/240VAC. This unit provides 22kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC/DC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC
- Line Rated Current:
- 40 A
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Net Weight:
- 0.621 kg
- Sustainable Offer Status:
- Green Premium product
- Product Certifications:
- UL Listed || CSA
- Circularity Profile:
- N/A
- Depth:
- 74 mm
- Poles Description:
- 3P
- Height:
- 79 mm
- Mounting Mode:
- bolt-on
- Circuit Breaker Type:
- standard
- Electrical Connection:
- box lugs
- Warranty:
- 18 months
- Product Or Component Type:
- miniature circuit-breaker
- Rohs Exemption Information:
- Yes
- Eu Rohs Directive:
- Compliant with Exemptions
- Tightening Torque:
- 5.6-5.6 N.m
- Accessory / Separate Part Type:
- shunt trip 12/24 V AC/DC
- Range Of Product:
- QO
- Mercury Free:
- Yes
- Awg Gauge:
- AWG 8...AWG 2 copper or aluminium
- Number Of Spaces Required:
- 4
- Width:
- 76 mm
- Ambient Air Temperature For Operation:
- 40 °C
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Circuit Breaker Application:
- HACR rated
- Breaking Capacity:
- 22 kA 120/240 V AC 50/60 Hz || 22 kA 240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz
