Schneider Electric QOB35035 Miniature Circuit Breaker 240V 50A
Schneider Electric
$351.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 50A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product is rated for operation at 50 degrees C. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Line Rated Current:
- 50 A
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Toxic Heavy Metal Free:
- Yes
- Mercury Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Net Weight:
- 0.404 kg
- Awg Gauge:
- AWG 8...AWG 2 copper or aluminium
- Poles Description:
- 3P
- Product Or Component Type:
- miniature circuit-breaker
- Range Of Product:
- QO
- Number Of Spaces Required:
- 3
- Halogen Content Performance:
- Halogen free product
- Warranty:
- 18 months
- Height:
- 79 mm
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC
- Depth:
- 74 mm
- Product Certifications:
- UL Listed || CSA
- Circuit Breaker Application:
- HACR rated
- Width:
- 57 mm
- Tightening Torque:
- 5-5 N.m
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Eu Rohs Directive:
- Compliant with Exemptions
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Ambient Air Temperature For Operation:
- 50 °C
- Electrical Connection:
- box lugs
- Sustainable Offer Status:
- Green Premium product
- Circuit Breaker Type:
- standard
- Circularity Profile:
- N/A
- Mounting Mode:
- bolt-on
- Rohs Exemption Information:
- Yes
