Schneider Electric QOB370FT Miniature Circuit Breaker 240V 70A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 70A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a fungal treatment. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Net Weight:
- 0.503 kg
- Circuit Breaker Type:
- standard
- Mercury Free:
- Yes
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Mounting Mode:
- bolt-on
- Poles Description:
- 3P
- Number Of Spaces Required:
- 3
- Ambient Air Temperature For Operation:
- 40 °C
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Range Of Product:
- QO
- Product Certifications:
- UL Listed || CSA
- Circuit Breaker Application:
- HACR rated
- Line Rated Current:
- 70 A
- Electrical Connection:
- box lugs
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Width:
- 57 mm
- Eu Rohs Directive:
- Compliant with Exemptions
- Product Or Component Type:
- miniature circuit-breaker
- Tightening Torque:
- 5.6-5.6 N.m
- Awg Gauge:
- AWG 8...AWG 2 copper or aluminium
- Rohs Exemption Information:
- Yes
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Height:
- 79 mm
- Depth:
- 74 mm
