Schneider Electric QOB370VH1021 Miniature Circuit Breaker 240V 70A

(No reviews yet) Write a Review

Write a Review

Schneider Electric QOB370VH1021 Miniature Circuit Breaker 240V 70A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

QOB370VH1021

UPC:

785901728436

MPN:

Condition:

New

Circularity Profile:

N/A

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Net Weight:

0.617 kg

Height:

79 mm

Warranty:

18 months

Tightening Torque:

5.6-5.6 N.m

Sustainable Offer Status:

Green Premium product

Ambient Air Temperature For Operation:

40 °C

Poles Description:

3P

Breaking Capacity:

22 kA 120/240 V AC 50/60 Hz || 22 kA 240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz

Mercury Free:

Yes

Rohs Exemption Information:

Yes

Width:

76 mm

Product Certifications:

UL Listed || CSA

Circuit Breaker Application:

HACR rated

Eu Rohs Directive:

Compliant with Exemptions

Accessory / Separate Part Type:

shunt trip 120/208/240 V AC

Line Rated Current:

70 A

Mounting Mode:

bolt-on

[Ue] Rated Operational Voltage:

120/240 V AC || 240 V AC || 120 V AC

Electrical Connection:

box lugs

Product Or Component Type:

miniature circuit-breaker

Depth:

74 mm

Halogen Content Performance:

Halogen free product

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Awg Gauge:

AWG 8...AWG 2 copper or aluminium

Circuit Breaker Type:

standard

Range Of Product:

QO

California Proposition 65:

WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Number Of Spaces Required:

4

Brochure:

View

Catalog:

View

Datasheet:

View
