Schneider Electric QOB3905273 Miniature Circuit Breaker 240V 90A
Schneider Electric
$503.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 90A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes ring terminals. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Circularity Profile:
- N/A
- Tightening Torque:
- 5.6-5.6 N.m
- Halogen Content Performance:
- Halogen free product
- Circuit Breaker Application:
- HACR rated
- Line Rated Current:
- 90 A
- Rohs Exemption Information:
- Yes
- Mounting Mode:
- bolt-on
- Depth:
- 74 mm
- Product Or Component Type:
- miniature circuit-breaker
- Range Of Product:
- QO
- Warranty:
- 18 months
- Circuit Breaker Type:
- standard
- Eu Rohs Directive:
- Compliant with Exemptions
- Net Weight:
- 0.513 kg
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC
- Ambient Air Temperature For Operation:
- 40 °C
- Awg Gauge:
- AWG 4...AWG 2/0 copper
- Number Of Spaces Required:
- 3
- Mercury Free:
- Yes
- Product Certifications:
- UL Listed || CSA
- Height:
- 89 mm
- Electrical Connection:
- ring tongue
- Sustainable Offer Status:
- Green Premium product
- Width:
- 57 mm
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Poles Description:
- 3P
